Ceramic Fiber Bulk

Introduction

Parameters

Application

Packaging

Introduction

Ceramic fiber friction material is made from standard ceramic fiber blown bulk through shear, slag removal processes, and secondary processing, as one of ideal raw material for production of friction materials.

Low thermal conductivity

Low thermal capacity and excellent thermal insulation property

High temperature stability , Resistance to thermal shock

Good tensile strength

Corrosion resistance

Excellent sound absorption, Fire protection and chemical corrosion resistance

Technical Parameters

Item Product		COMMON	ST	HP	HA	HZ
Classification Temp(ºC)		1100	1260	1260	1360	1430
Working Temp (ºC)		<1000	1050	1100	1200	1350
Color		white	white	white	white	white
Fiber dia(μm)	Blowing	2~3	2~3	2~3	2~3	2~3
	Swinging	3~4.5	3~4.5	3~4.5	3~4.0	3~4.0
Chemical composition(%)	Al2O3	44	46	47~49	52~55	39~40
	Al2O3+SiO2	96	97	99	99	-
	Al2O3+SiO2+ZrO2	-	-	-	-	99
	ZrO2	-	-	-	-	15-17

Application Of Ceramic Fiber Bulk

Fill the flange gaps or expansion joints of petrochemical reactors and power plant boilers. Utilize the flexible nature of the cotton to form a high-temperature-resistant sealing barrier, preventing heat leakage.

Fill the insulation layers of the waste incinerator and the exhaust gas purification device with ceramic fiber loose cotton, which can resist high-temperature corrosive gases and extend the service life of the equipment.

The equipment gaps in the diesel engine room of the vessel are filled with ceramic fiber loose cotton, which not only achieves high-temperature insulation but also absorbs mechanical noise, meeting the maritime fire prevention regulations.

$It is used as the backfill material for the refractory layer of kilns. By virtue of the low thermal conductivity of ceramic fiber loose cotton, it reduces heat loss and enhances energy efficiency.$

It is used as the backfill material for the refractory layer of kilns. By virtue of the low thermal conductivity of ceramic fiber loose cotton, it reduces heat loss and enhances energy efficiency.

$As a repair material for the refractory layer of industrial heat treatment furnaces, ceramic fiber loose cotton can quickly fill the damaged areas and reduce the downtime of the equipment.$

As a repair material for the refractory layer of industrial heat treatment furnaces, ceramic fiber loose cotton can quickly fill the damaged areas and reduce the downtime of the equipment.
